Just Camp Active Low Profile T 7052 DBM Active
Price (incl. VAT) a)
Standard chassis Fiat Ducato Light Low Platform
Standard engine 140 MultiJet 3
kW (bhp) 103 (140)
Emission standards Euro 6e/6e-bis
Overall length, approx. 740
Overall width, approx. 233
Overall height, approx. 294
Headroom in living area, approx. 213
Towable load braked/unbraked 2000 / 750
Wheelbase, approx. 4035
Bed dimension: Front bed, L x W, approx. 200 x 140 - 120 (○)
Bed dimension: Central / middle bed, L X W, approx. 210 x 120 - 80 (○)
Bed dimension: Rear bed, L x W, approx. 190 x 150
Sleeping berths standard / max. 2 / 5 (○)
Mass in running order (+/-5%)* 2800 (2660 to 2940)*
Manufacturer-specified mass for optional equipment* 255.65
Technically permissible maximum laden mass* 3499
Permitted number of seats (including driver)* 4 - 5 (○)
Refrigerator volume (thereof freezer), approx. 137 (15) / 137 (15) (○)
Waste water tank, approx. 90
Fresh water tank capacity, total/ Fresh water tank capacity at driving filling 116 / 20
Measurement storage opening right (W x H) 95 x 115
Measurement storage opening left (W x H) 95 x 95 (○)
a) This is a recommended retail price based on German retail prices. Prices in other countries may differ due to currency conversion and country-specific VAT, fees and import duties. For the latest information, please always enquire with a local dealer about the prices applicable in your country.

* The specified mass in running order is a default value defined in the type-approval procedure. Due to manufacturing tolerances, the actual weighed mass in running order may deviate from the value stated above. Deviations of up to ± 5 % of the mass in running order are legally permissible and possible. The permissible range in kilograms is given in brackets after the mass in running order.  The manufacturer-specified mass for optional equipment is a calculated value for each type and layout that Dethleffs uses to determine the maximum weight available for factory-fitted optional equipment. The limitation of optional equipment is intended to ensure that the minimum pay-mass, i.e. the legally prescribed free mass for baggage and retrofitted accessories, is actually available for the vehicle load capacity of the vehicles delivered by Dethleffs.  The real weight of your vehicle ex works can only be determined when it is weighed at the end of the line. If, in exceptional cases, the weighing shows that the actual load capacity falls below theminimum pay-mass despite limiting the optional equipment due to a permissible weight deviation, we will check together with your trade partner and you whether we should, for example, increase the load capacity of the vehicle, reduce the number of seats or remove optional equipment before delivering the vehicle.  The technically permissible maximum laden mass of the vehicle and the technically permissible maximum mass on the axle must not be exceeded.

(○) Optional
Length
740 cm
Width
233 cm
Height
294 cm
Sleeping berths max.
5
Technically permissible maximum laden mass
3.499 kg
Price
Low Profile

Layout
Active T 7052 DBM

Gas bottle box can be conveniently loaded (gas bottles positioned next to each other)

Centre bathroom can be separated from the living area

Comfortable access to the double bed due to platform

Height adjustable Queens bed

Living area without trip hazards, platform moved to the driver's cabin

Exterior View

70 cm wide habitation door with central locking

Proven Lifetime body construction with GRP outer skin and excellent insulation

Living in the Just Camp Active

Living

  • Just all you need

    Modern, handleless overhead locker doors with soft-close function. The “Light Moments” lighting system perfectly sets the mood after sunset.

  • “Light Moments” lighting system

    Numerous direct and indirect light sources create a cosy, atmospheric setting.

Sleeping

  • Enjoy a good night’s sleep!

    Comfortable and practical: the queen bed is height-adjustable and accessible from three sides. This means you can either have more space in the rear garage or extra headroom in the bedroom • T 7052 DBL

  • Enjoy a good night’s sleep!

    Versatile sleeping arrangements: the comfortable single beds can also be easily combined to form a double bed (option) • T 7052 EB

  • Enjoy a good night’s sleep!

    Electrically operated two-person pull-down bed above the seating lounge (option)

Bathroom

  • A great way to start the day

    Space aplenty: the washroom and shower cubicle can be combined to form a large bathroom • T 7052 DBL

  • A great way to start the day

    Bright and modern washroom with practical mirror that can be moved sideways, as well as numerous shelves and storage options • I 7052 EB

Cooking

  • Simply delicious

    Flexible Multiflex rail system with hooks. Additional hook-in elements are available from Dethleffs Original Accessories. Economical LED spotlights bathe the kitchen in bright light.

  • Simply delicious

    The spacious kitchen cabinets offer enough space for pots and pans • T 7052 DBL

  • Simply delicious

    “Just start cooking” is the motto here. The 2-burner gas hob features a practical hinged cover and electric ignition

Specification

1
  • “Light Moments” ambient lighting above the overhead lockers and on the wall surfaces
  • Dethleffs Naviceiver featuring DAB+, Truck Navigation, Apple CarPlay and Android Auto
  • Aerodynamic cab hood with opening window
  • Double-glazed flush-fitting windows

    (Example shown)
  • Cab blinds
  • Omnistor cassette awning

Variety of choice

Heron (partial textile-leather)
Noce Nagano

Dimensions

1
2
3
4
5

T 7052 DBM Active

1 Length 740 cm
2 Height 294 cm
3 Width 233 cm
4 Headroom 213 cm
5 Wheelbase 4035 mm

Engine

140 MultiJet 3

Fuel Diesel

6-gear

CCM
2.184
Power
140 hp

Weight

Technically permissible maximum laden mass
3.499 kg
Mass in running order
2.800 kg
Manufacturer-specified mass for optional equipment
255,65 kg
Towable load braked
2.000 kg
Towable load unbraked
750 kg
Electrical installation
Standard equipment
On-board control panel
Awning light 12 V
Light Moments: Indirect ambient lighting above the overhead lockers
Number of sockets 1x 12V, 8x 230V, 4x USB
Light Moments: Indirect wall surface ambient lighting
Pre-wiring for solar
LED lighting throughout the vehicle
EBL with separate FI protection switch
Automatic switch-on/disconnect for starter battery, leisure battery and refrigerator
Spotlights in the roof lining above the habitation door
Light Moments: illuminated kitchen splashback
Leisure battery AGM, 95 Ah
Pre-wiring for roof A/C
Dethleffs Naviceiver incl. DAB+, truck navigation, wireless Apple CarPlay and Android Auto
Rear view camera (single camera)
Pre-wiring for satellite system
Optional equipment
Solar power system 100 watt
Second leisure battery AGM, 95 Ah
Heating
Standard equipment
Gas hot air heating 6kW with hot water boiler
Heating in the seating unit for optimum heat distribution, built-in
Digital control element for hot air heating
Optional equipment
Floor heating electric (partial)
Gas hot air heating 6kW with 1.8kW electric heating element and hot water boiler incl. digital control panel
Water supply
Standard equipment
Submersible pump
Fresh water tank in insulated and heated area
Optional equipment
Switch for water pump
Insulated waste water tank
Gas supply
Standard equipment
Storage space for 2 gas bottles with a filling weight of 11 kg each
Optional equipment
Automatic gas cylinder switchover incl. crash sensor and EisEx
